| 빈도: | 868/915MHz | V.S.W.R: | <= 2.0 |
|---|---|---|---|
| 안테나 게인: | 5.8 DBI | 편광: | 선의 |
| 임피던스: | 50 옴 | 라디에이터 재료: | 놋쇠 |
| 플라스틱 재료: | 유리 섬유 | 커넥터 유형: | 엔 숫놈 커넥터 |
| 작동 온도: | -20 ℃ ~ +60 ℃ | 저장 온도: | -40 ℃ ~ +80 ℃ |
| 치수: | 20*800mm | 구조 양식: | 표면 안테나 |
| VSWR: | 1.5~2 | 얻다: | 5.8 DBI |
| 모델 번호: | TX-HG023 | ||
| 강조하다: | 868MHz fiberglass base station antenna,915MHz Helium HNT antenna,5.8dBi fiberglass antenna |
||
| Frequency | 868/915 MHz |
|---|---|
| V.S.W.R | <= 2.0 |
| Antenna Gain | 5.8 dBi |
| Polarization | Linear |
| Impedance | 50 Ohm |
| Material of Radiator | Brass |
|---|---|
| Material of Plastic | Fiberglass |
| Connector Type | N male connector |
| Operation Temperature | -20˚C ~ +60˚C |
|---|---|
| Storage Temperature | -40˚C ~ +80˚C |
Teng Xiang Electronics is an experienced manufacturer specializing in RF products, including antennas, RF coaxial cable assemblies, and RF connectors. We deliver innovative solutions for the wireless industry, serving 5G, 4G (LTE), 3G, 2G, WiFi, ISM, IoT, Iridium communications, and GPS/GLONASS/BeiDou applications.
With expertise in telecommunications, security, automotive, medical, and IoT markets, we provide customized solutions through in-house design, R&D, and manufacturing. Our commitment to quality and customer service ensures excellent products and partnerships with all clients.
